    Pre Fab School Building Transportable Portable Classrooms

    Ask Lasest Price
    Brand Name : KHOME
    Model Number : KHPC
    Certification : CE, SGS, PVOC
    Price : USD2050/set~USD2100/set
    Payment Terms : T/T, L/C
    Supply Ability : 8000 Square Meters/month
    Delivery Time : 30 Days
    • Product Details
    • Company Profile

    Pre Fab School Building Transportable Portable Classrooms


    Customized Pre-fab School Building Durable Transportable Classrooms

    Features:

    1. High Quality: Certificated by ISO, CE, SGS, PVOC.
    2. All Size Available: Standard or Customized.
    3. Mature Teamwork: Complete and orderly team structure.
    4. Export Ability: Having a good exporting ability and relative exporting qualifications and experience.
    5. Reasonable Price: Will give you the best price
    6. Delivery: Delivery on time

    Wide applications:

    A. Office
    B. Mining camp/labor camp
    C. Hotel or Motel
    D. Workers' accommodation
    E. School
    F. Canteen
    G. Villa
    H. Family apartment
    I. Public toilet or shower
    J. Clinic or hospital

    ItemSpecificationPictures
    Part 1: Roof System (roof plate + roof purlin + roof insulation + ceiling)
    1Roof Plate

    Roof tile is 0.5 mm thickness steel sheet;

    Pre-coated and color coated;

    2Roof Purlin

    1pc 40x80mm Galvanized Square tube
    + 2pcs 40x60mm Galvanized Square tube

    + 5pcs 40x80mm Galvanized Square tube;

    3Roof Insulation50 mm glass wool insulation material;
    4
    Ceiling

    Ceiling is 0.4 mm thickness shaped steel plate;

    Pre-coated and color coated;

    Part 2: Steel Frame (Corner post + column + beam + bolt)
    1Corner Connection Part

    Material: 4 mm Thickness Shaped Steel, surface spray treated by machine after repeatedly polished;

    Size: 160* 160* 160 mm (Bottom)

    &160* 160* 180 mm (Top);

    2Column

    Material: 2.3mm Thickness galvanized steel structure, surface spray treated by machine after repeatedly polished;


    Size: 160* 160* 2480mm;

    3Top and Floor Long Beam

    Material: 2.3mm Thickness galvanized steel structure, surface spray treated by machine after repeatedly polished;

    Size 1: 3680* 60* 160 mm;

    Size 2: 5680* 60* 160 mm;

    4Top & Floor Short Beam

    Material: 2.3mm Thickness galvanized steel structure, surface spray treated by machine after repeatedly polished;

    Size 1: 2680* 60* 160 mm;

    5Bolt

    High strength galvanized steel bolt;

    To fix the Corner Connection Part and beam, Corner Connection Part and column;

    Part 3: Floor System (Floor structure + floor panel + floor leather)+Wall Panel
    1Floor Purlin

    Material: 10pcs 40x80mm Galvanized Square tube
    +4pcs 40x80mm Galvanized Square tube
    +2pcs 30x50mm Galvanized Square tube;

    2Floor Panel

    18 mm MGO board

    3Wall Panel

    50 mm rock wool sandwich Panel;

    Outside color is light silver gray (0.38mm thickness steel );
    Inside is white color steel (0.38mm thickness steel ).

    Part 4: Drainage system (Top drainage channel + drain pipe)
    1Water drain pipe and channel

    Water drain pipe:
    Diameter: 50mm
    Length: 2700mm;
    Water drain channel: 90(W)x50(H)mm;

    Part 5 : Door & window system
    1Standard Door

    Size 1: 930mm*2000mm
    Material: sandwich panel/steel door;

    2Window

    Size 1: 930mm*1200mm
    Plastic steel single glass sliding window (including screens) With 0.35mm Double glass and strength pvc window frame/Glass Window;
    Window rail is smooth.

    Part 6: Electricity System
    1Lamp

    Type: LED energy saving lamp;
    Power: 24W
    Include: Two sockets and one switch;
    Note: The socket will be equipped according to the local standard.
    Includes: electric wire and conduit;
    Use: The electric wire will be in the conduit and go through the wall panel for concealed installation.

    2Socket & Switch
    3Electric Wire
    4Air Circuit Breaker
    Part 7: Internal Decoration
    1Internal Corner

    Material: PVC;
    Includes: Vertical internal corner and horizontal internal corner.

    2Steel Plate for Internal Connection

    Material: Stainless Steel;
    Used on the joints between two bottom frames when different containers connected with each other.

    3Floor Leather

    Material: PVC
    Thickness: 1.6mm
    Features: moisture proof; wear resisting;
    anti-corrosive and thermal insulation.

    Part 8: Installation Accessories
    1SealantUsed for the joints of doors and windows for better waterproof.
    2Structure AdhesiveUsed for the reinforcement and seal of the steel frames.
    3ScrewsInclude: rivets, bolts, drill tail screw;
