Low Cost Smart Prefab Portable Emergency Shelter Social House
I. Introduction
The T type house is the most economical and applicable small and
medium-sized temporary accommodation and office buildings, with a
span of about 5m and a length of about 1.2m (or 1m) as the standard
module expansion, have flexible layout.
It is also a kind of emporary buildings with the longest history
and the widest distribution which have been used for 40 years.
After 15 technical improvements, the products have been widely
distributed in all parts of the country and nearly 100 countries
and regions around the world.
It is one of the fastest temporary buildings can be installed, with
4 people a day and 130 ㎡. A 40-foot container can carry about 330
㎡. And it is with the best disassembly performance can be
disassembled 10 times.
II. Design description
| 1 | Unit house area | 102 sqm | | 2 | Capacity | 2-4 people | | 3 | Floor number | 1 | | 4 | Bedroom qty. | 2 | | 5 | Toilet qty. | 1 | | 6 | Kitchen room | 1 | | 7 | Living room | 1 |
III. Main material specification
| Part 1:Roof System | | Roof Panel | 50mm rock wool sandwich panel; | | Color is common color: scarlet/blue | | Herringbone | Galvanized square tube: 40*80*1.4mm; | | Firm, strong corrosion resistance and has a long service life | | Roof Purlin | Galvanized square tube: 40*60*1.4mm; | | Strong, durable, corrosion resistance and has a long service life. | | Ring Beam | Galvanized square tube: 40*60*1.4mm; | | Firm, strong corrosion resistance and has a long service life | | Ceiling | Steel plate ceiling | | Strong and corrosion resistance | | Part 2:Steel Frame (Bottom Steel Structure+Column+Bolt ) | | Bottom Steel Structure | 1. Foot support: 40mm(Width)*80mm(Length) | | 2. Bottom purlin: 40mm(Width)*80mm(Height) | | Column | Galvanized square tube: 80*80*2.0mm; | | Safe, strong and corrosion resistance, | | The color is glossy and can last for a long time. | | Bolt | High strength galvanized steel bolt | | Firm, strong and corrosion resistance | | Part 3: Wall Panel | | Wall Panel | 50mm rock wool sandwich panel,( 0.38mm steel plate on both sides); | | Color is a common color: white grey. |
IV. About us
V. FAQ:
Q1: Delivery time
A1: The delivery time is according to your quantity and color,
generally it is within 15-30 days.
Q2: Month Capacity
A2: Prefab house: 220,000m2, Container house: 1,800units.
Q3: How to install
A3: We will send install instruction and video for you, technicians
will be sent to help you if it is necessary.
However, the visa fee, air tickets, accommodation, wages will be
provided by buyers.
Q4: Pre-order work
A4: Proposal drawing, Shop drawing, 3D drawing, Materials photos,
Finished project photos, design works are available according to
your requirements.
|
