| Item | Specification |
| Part 1: Roof System (roof plate + roof purlin + roof insulation +
ceiling) |
| i | Roof Plate | Roof tile is 0.5 mm thickness steel sheet; Pre-coated and color coated;
Strong and corrosion resistance. |
| ii | Roof Purlin | 1pc 40x80mm Galvanized Square tube + 2pcs 40x60mm Galvanized Square
tube + 5pcs 40x80mm Galvanized Square tube;
Firm, strong corrosion resistance and has a long service life. |
| iii | Roof Insulation | 50 mm glass wool insulation material;
Fireproof A1 class, non combustion. |
iv | Ceiling | Ceiling is 0.4 mm thickness shaped steel plate;
Pre-coated and color coated;
Strong and corrosion resistance.
|
| Part 2: Steel Frame (Corner post + column + beam + bolt) |
| i | Corner Connection Part | Material: 4 mm Thickness Shaped Steel, surface spray treated by
machine after repeatedly polished;
Size: 160* 160* 160 mm (Bottom) &160* 160* 180 mm (Top);
Feather: Safe, strong and corrosion resistance. The color is glossy and can last for a long time. |
| ii | Column | Material: 2.3mm Thickness galvanized steel structure, surface spray
treated by machine after repeatedly polished;
Size: 160* 160* 2480mm; Feather: Safe, strong and corrosion resistance. The color is glossy and can last for a long time. |
| iii | Top and Floor Long Beam | Material: 2.3mm Thickness galvanized steel structure, surface spray
treated by machine after repeatedly polished;
Size 1: 3680* 60* 160 mm; Size 2: 5680* 60* 160 mm;
Feather: Safe, strong and corrosion resistance. The color is glossy and can last for a long time. |
| iv | Top & Floor Short Beam | Material: 2.3mm Thickness galvanized steel structure, surface spray
treated by machine after repeatedly polished;
Size 1: 2680* 60* 160 mm;
Feather: Safe, strong and corrosion resistance. The color is glossy and can last for a long time. |
| v | Bolt | High strength galvanized steel bolt;
To fix the Corner Connection Part and beam, Corner Connection Part
and column;
Firm, strong and corrosion resistance. |
| Part 3: Floor System (Floor structure + floor panel + floor
leather) |
| i | Floor Purlin | Material: 10pcs 40x80mm Galvanized Square tube+4pcs 40x80mm
Galvanized Square tube+2pcs 30x50mm Galvanized Square tube;
Strong, durable, corrosion resistance and has a long service life. |
| ii | Floor Panel |
18 mm MGO board;
Feathers: Good fire and moisture resistance; Green environmental protection;
|
| Part 4 | Wall Panel | 50 mm Rock wool sandwich Panel; Outside color is light silver gray (0.4mm thickness steel ); Inside is white color steel (0.4mm thickness steel ). |
| Part 5: Drainage system (Top drainage channel + drain pipe) |
| i | Water drain pipe and channel | Water drain pipe: Diameter: 50mm Length: 2700mm;
Water drain channel: 90(W)x50(H)mm; Greatly water-proof even under heavy rain. |
| Part 6: Door & window system |
| i | Door | Entrance door: steel door; The interior is filled with composite wood to make the door heavy
and strong; Width 930mm, height 2000mm. |
| iii | Window | Plastic steel single glass sliding window (including screens); With 0.35mm Double glass and strength pvc window frame; Width 930mm, height 1200mm; Window rail is smooth. |
| Part 7: Connection Accessories |
| i | Sealing Strip | Used on the joint between wall panel and steel frame for better
waterproof performance. |
| ii | Lock | Used on the joint between wall panel and steel frame for better
waterproof performance. |
| iii | Joints Cover | Material: Rubber When there are two containers connected with each other, it is used
in the joint between two containers for better fixation. |
| iv | Waterproof Tape | Type: Self-adhesive Features: Waterproof; reliably sealing; strong adhesive strength;
anti-corrosive |
| Part 8: Electricity System |
| i | Lamp | Type: LED energy saving lamp; Power: 24W |
| ii | Socket & Switch | Include: Two sockets and one switch; Note: The socket will be equipped according to the local standard. |
| iii | Electric Wire | Includes: electric wire and conduit; Use: The electric wire will be in the conduit and go through the
wall panel for concealed installation. |
| iv | Air Circuit Breaker | Features: short-circuit protection; overload protection; under
voltage protection. |
| Part 9: Internal Decoration |
| i | Internal Corner | Material: PVC; Includes: Vertical internal corner and horizontal internal corner. |
| ii | Steel Plate for Internal Connection | Material: Stainless Steel; Used on the joints between two bottom frames when different
containers connected with each other. |
| iii | Floor Leather | Material: PVC Thickness: 1.6mm Features: moisture proof; wear resisting; anti-corrosive and thermal insulation.
Feathers: Excellent appearance, affordable, easy to clean and green
environmental protection; |
| Part 10: Installation Accessories |
| i | Sealant | Used for the joints of doors and windows for better waterproof. |
| ii | Structure Adhesive | Used for the reinforcement and seal of the steel frames. |
| iii | Screws | Include: rivets, bolts, drill tail screw; |
