| Part 1: Roof System (roof plate + roof purlin + roof insulation +
ceiling) |
| I | Roof Plate | Roof tile is 0.5 mm thick steel sheet; Pre-coated and color coated; |
| Strong and corrosion resistance. |
| ii | Roof Purlin | 1pc 40x80mm Galvanized Square tube + 2pcs 40x60mm Galvanized Square
tube + 5pcs 40x80mm Galvanized Square tube; |
| Firm, strong corrosion resistance and has a long service life. |
| iii | Roof Insulation | 50 mm glass wool insulation material; |
| Fireproof A1 class, non-combustion. |
| iv | Ceiling | The ceiling is 0.4 mm thickness shaped steel plate; Pre-coated and
color coated; |
| Strong and corrosion resistance. |
| Part 2: Steel Frame (Corner post + column + beam + bolt) |
| I | Corner Connection Part | Material: 4 mm Thickness Shaped Steel, surface spray treated by
machine after repeatedly polished; |
| Size: 160* 160* 160 mm (Bottom) &160* 160* 180 mm (Top); |
| Feather: Safe, strong, and corrosion resistance. |
| The color is glossy and can last for a long time. |
| ii | Column | Material: 2.3mm Thickness galvanized steel structure, surface spray
treated by machine after repeatedly polished; |
| Size: 160* 160* 2480mm; |
| Feather: Safe, strong, and corrosion resistance. |
| The color is glossy and can last for a long time. |
| iii | Top and Floor Long Beam | Material: 2.3mm Thickness galvanized steel structure, surface spray
treated by machine after repeatedly polished; |
| Size 1: 3680* 60* 160 mm; |
| Size 2: 5680* 60* 160 mm; |
| Feather: Safe, strong, and corrosion resistance. The color is
glossy and can last for a long time. |
| iv | Top & Floor Short Beam | Material: 2.3mm Thickness galvanized steel structure, surface spray
treated by machine after repeatedly polished; |
| Size 1: 2680* 60* 160 mm; |
| Feather: Safe, strong, and corrosion resistance. |
| The color is glossy and can last for a long time. |
| v | Bolt | High strength galvanized steel bolt; |
| To fix the Corner Connection Part and beam, Corner Connection Part
and column; |
| Firm, strong, and corrosion resistance. |
