Movable Flat Pack Container School Portable Classrooms With Dining
Room And Offices
I. Introduction
The Portable school and classrooms made by container houses can be
recycled for more than 15 years. It is environmental protection and
much more energy-efficient using sandwich panel and light steel
structure as main material.
The classroom can be combined with multiple container units to form
different shapes and can be beautiful like villas, and can be moved
and used at any time without generating any operational waste.
The flat pack container has good sealing performance, and a strict
manufacturing process makes this kind of movable house have good
water tightness, all steel material, shockproof, waterproof,
windproof, fireproof, anticorrosive.
II. Design description
| 1 | Building area | 378 sqm | | 2 | Capacity | 1105 students | | 3 | Floor number | 1 | | 4 | Dining & Kitchen | 54 sqm | | 5 | Classroom qty. | 3 | | 6 | Administrator office | 36 sqm | | 7 | Staff office | 54 sqm | | 8 | Boys' toilet | 36 sqm | | 9 | Girls' toilet | 36 sqm |
III. Main material specification
| Part 1: Roof System (roof plate + roof purlin + roof insulation +
ceiling) | | I | Roof Plate | Roof tile is 0.5 mm thick steel sheet; Pre-coated and color coated; | | Strong and corrosion resistance. | | ii | Roof Purlin | 1pc 40x80mm Galvanized Square tube + 2pcs 40x60mm Galvanized Square
tube + 5pcs 40x80mm Galvanized Square tube; | | Firm, strong corrosion resistance and has a long service life. | | iii | Roof Insulation | 50 mm glass wool insulation material; | | Fireproof A1 class, non-combustion. | | iv | Ceiling | The ceiling is 0.4 mm thickness shaped steel plate; Pre-coated and
color coated; | | Strong and corrosion resistance. | | Part 2: Steel Frame (Corner post + column + beam + bolt) | | I | Corner Connection Part | Material: 4 mm Thickness Shaped Steel, surface spray treated by
machine after repeatedly polished; | | Size: 160* 160* 160 mm (Bottom) &160* 160* 180 mm (Top); | | Feather: Safe, strong, and corrosion resistance. | | The color is glossy and can last for a long time. | | ii | Column | Material: 2.3mm Thickness galvanized steel structure, surface spray
treated by machine after repeatedly polished; | | Size: 160* 160* 2480mm; | | Feather: Safe, strong, and corrosion resistance. | | The color is glossy and can last for a long time. | | iii | Top and Floor Long Beam | Material: 2.3mm Thickness galvanized steel structure, surface spray
treated by machine after repeatedly polished; | | Size 1: 3680* 60* 160 mm; | | Size 2: 5680* 60* 160 mm; | | Feather: Safe, strong, and corrosion resistance. The color is
glossy and can last for a long time. | | iv | Top & Floor Short Beam | Material: 2.3mm Thickness galvanized steel structure, surface spray
treated by machine after repeatedly polished; | | Size 1: 2680* 60* 160 mm; | | Feather: Safe, strong, and corrosion resistance. | | The color is glossy and can last for a long time. |
IV. About us
V. FAQ
Q: How to buy?
A: You can provide us your drawing, and we will produce as your
drawings.
Q: How to pay?
A: TT and L/C are acceptable and TT will be more appreciated. 30%
deposit before producing, 70% balance before loading by TT.
Q: What is the delivery time?
A: It depends on the order quantities. Generally speaking, the
delivery time will be within 15 to 30 days.
Q: How to ship?
A: Loading by sea shipping container.
Q: How to install after the goods arriving destination?
A: We will provide detailed illustration photos and videos to you.
If it is necessary, we will send technicians to help you. However,
the visa fee, air tickets, accommodation, wages will be borne by
buyers. |
