Prefabricated Container Clinic Fast Assembly With Modular Design
I. Introduction
Khome is a leading manufacturer of temporary prefabricated
accommodation. Our products are widely used for in various kinds of
industries. Now, this kind of modular house has become ideal house
applications.
Fast Time response is needed urgently when the emergency is
occurred, so the high-efficiency solutions are required to solve
the problem. And this prefabricated modular house is highly suited
for the use of clinics, hospitals, health care centers, diagnose
rooms, laboratories, etc.
II. Design introduction
This prefabricated container clinic is designed with an area of 72
square meters, which contains an IPC room, a reception room, a
kitchen and dining room, toilet, and a ward with two beds.
III. Product show
| Part 1: Roof System (roof plate + roof purlin + roof insulation +
ceiling) | | I | Roof Plate | Roof tile is 0.5 mm thick steel sheet; Pre-coated and color coated; | | Strong and corrosion resistance. | | ii | Roof Purlin | 1pc 40x80mm Galvanized Square tube + 2pcs 40x60mm Galvanized Square
tube + 5pcs 40x80mm Galvanized Square tube; | | Firm, strong corrosion resistance and has a long service life. | | Part 2: Steel Frame (Corner post + column + beam + bolt) | | I | Corner Connection Part | Material: 4 mm Thickness Shaped Steel, surface spray treated by
machine after repeatedly polished; | | Size: 160* 160* 160 mm (Bottom) &160* 160* 180 mm (Top); | | Feather: Safe, strong, and corrosion resistance. | | The color is glossy and can last for a long time. | | ii | Column | Material: 2.3mm Thickness galvanized steel structure, surface spray
treated by machine after repeatedly polished; | | Size: 160* 160* 2480mm; | | Feather: Safe, strong, and corrosion resistance. | | The color is glossy and can last for a long time. | | iii | Top and Floor Long Beam | Material: 2.3mm Thickness galvanized steel structure, surface spray
treated by machine after repeatedly polished; | | Size 1: 3680* 60* 160 mm; | | Size 2: 5680* 60* 160 mm; | | Feather: Safe, strong, and corrosion resistance. The color is
glossy and can last for a long time. | | iv | Top & Floor Short Beam | Material: 2.3mm Thickness galvanized steel structure, surface spray
treated by machine after repeatedly polished; | | Size 1: 2680* 60* 160 mm; | | Feather: Safe, strong, and corrosion resistance. | The color is glossy and can last for a long time.
|
IV. Delivery
|
